High Efficiency Counterbalance Forklift Truck 4 Ton Capacity 3m - 6m Lift Height

Good quality Diesel Forklift Truck for sales
Good quality Diesel Forklift Truck for sales
I'm Online Chat Now

High Efficiency Counterbalance Forklift Truck 4 Ton Capacity 3m - 6m Lift Height

China High Efficiency Counterbalance Forklift Truck 4 Ton Capacity 3m - 6m Lift Height supplier
High Efficiency Counterbalance Forklift Truck 4 Ton Capacity 3m - 6m Lift Height supplier High Efficiency Counterbalance Forklift Truck 4 Ton Capacity 3m - 6m Lift Height supplier

Large Image :  High Efficiency Counterbalance Forklift Truck 4 Ton Capacity 3m - 6m Lift Height

Product Details:

Place of Origin: CHINA
Brand Name: JAC
Certification: CE , ISO9001 , ISO14001 , OHSAS18001
Model Number: CPCD40H

Payment & Shipping Terms:

Minimum Order Quantity: 1UNIT
Price: negotiable
Delivery Time: 25 working days
Payment Terms: L/C, T/T
Supply Ability: 1000UNITS/Month
Contact Now
Detailed Product Description
Load Capacity: 4000KG Warranty: One Year
Power: Diesel Color: Red Or Orange
Lift Height: 3m-6m Engine Brand: Isuzu Or Xichai
HS CODE: 8427209000 Manufacturer: JAC

Counterbalanced Forklift , Forklift Powered By Diesel , 4 Ton Loading Capacity , Janpanese Isuzu Engine for Option ,





As a manufacturer of diesel forklifts in China, we offer two series of forklifts: the H series and the J series, which feature an adjustable steering wheel and seat, as well as a reasonable layout for each operating system, fully embodying ergonomic principles and effectively reducing Labor intensity.
The high-strength, built-in, suspended, integrated overhead shroud is made of thermal and acoustic insulation; the spacious cab ensures comfortable operation. When you work outside with a forklift, you may need a lot of power to lift, and then the JAC diesel forklift will be the right choice.



1. Small overall dimension,low centre of gravity, small turning radius, and excellent manoeuvrability.
2. The frame and the steering axle of the material handling equipment are engineered with shock absorber to reduce the impact and maximize the comfort during operation.

3. Multiple engines for selection.

4. The eco-friendly design of the diesel forklift offers full protection to both the user and the environment.



Parameters:

        Model Name CPCD40
1 Feture Power Type   Diesel
2 Load Capcity kg 4000
3 Load center mm 500
4 Lift height mm 3000
5 Free lift height mm 110
6 Forkk size L*W*H mm 1070×150×50
7 Mast tilt FR/RR . 6/12
8 Min turning Radius mm 2835
9 Min Right angle stacking aisle width mm 4525
10 Min right angle aisle width mm 2862
11 Min ground clearance mm 138
12 Height of overhead guard mm 2140
13 Overhang mm 490
14 Performance Max driving speed Full load km/h 20
15 Max Lifting speed Full load mm/s 380
16 Max drawbar pull Full load KN 21.8
17 Gradeabiity % 15
18 Dimension Overall length Without forks mm 2950
19 Over width mm 1410
20 Height mast lifted(with backrest) mm 4220
21 Height mast lowered mm 2120
22 Chassis Tyre Front   250-15-16PR
23 Rear   6.50-10-10PR
24 Wheelbase mm 1900
25 Tread FR/RR mm 1160/1065
26 Self weight Without load Kg 5205
27 Drive Battery Voltage / Capacity V/Ah 12/80
28 Engine Model   XC A498BPG
29 Rated Power kw/r.p.m 45/2500
30 Rated Torque Nm/r.p.m 198/1800
31 Bore * sTROKE mm 98×105
32 No.of Cylinder   4
33 Displacement L 3.168
34 Fuel tank capacity L 66
35 Transmission   1/1manual shift
36 Operating Pressure Mpa 14.5
37 Supplement Tire type (FR/RR)   Pneumatic
38 Numbers of wheels pcs 2/2
39 lowering speed (full load) mm/s 460
40 Lowering speed ( unload) mm/s 400
41 Axle load distribution (full load) (FR/RR) kg 8180/1025
42 Axle load distribution (unload) (FR/RR) kg 2090/3115









Feartures:



High Efficiency Counterbalance Forklift Truck 4 Ton Capacity 3m - 6m Lift Height
           High Efficiency Counterbalance Forklift Truck 4 Ton Capacity 3m - 6m Lift HeightHigh Efficiency Counterbalance Forklift Truck 4 Ton Capacity 3m - 6m Lift Height

         High Efficiency Counterbalance Forklift Truck 4 Ton Capacity 3m - 6m Lift Height  High Efficiency Counterbalance Forklift Truck 4 Ton Capacity 3m - 6m Lift Height
