Gas Powered LPG Forklift Trucks 3500KGS Load Capacity 3m - 6m Lift Height

China Gas Powered LPG Forklift Trucks 3500KGS Load Capacity 3m - 6m Lift Height supplier
Gas Powered LPG Forklift Trucks 3500KGS Load Capacity 3m - 6m Lift Height supplier Gas Powered LPG Forklift Trucks 3500KGS Load Capacity 3m - 6m Lift Height supplier Gas Powered LPG Forklift Trucks 3500KGS Load Capacity 3m - 6m Lift Height supplier

Large Image :  Gas Powered LPG Forklift Trucks 3500KGS Load Capacity 3m - 6m Lift Height

Product Details:

Place of Origin: CHINA
Brand Name: JAC
Certification: CE,ISO9001,ISO14001,OHSAS18001
Model Number: CPQD35(LPG)

Payment & Shipping Terms:

Minimum Order Quantity: 1UNIT
Price: negotiable
Delivery Time: 25 working days
Payment Terms: L/C, T/T
Supply Ability: 1000UNITS/Month
Contact Now
Detailed Product Description
Load Capacity: 3500KGS Warranty: One Year
Power: Liquefied Petroleum Gas Color: Red
Lift Height: 3m-6m Engine Brand: Nissan

Gas Powered Forklift With Load Capacity 3.5Ton , Nissan Engine , Orange Color





Advantages:

1. The JAC gasoline and LPG forklift is ergonomically designed to be safe, comfortable and efficient to operate as well as to technically meet the demands of local and international customers. This industrial forklift features an adjustable steering wheel and seat and an operating system layout that is convenient and easy to use.

2. The engine is equipped with a suspension shock-absorption device. The steering wheel is easy to maneuver and the low torque steering gear makes pivot steering easy. Different models of our gasoline forklift truck can be configured with various powerful and cost-effective engines, such as the Chinese Guangqing GQ491 engine, Japanese and K25 engine (4 cylinders /37.4kW), all of which meet requirements for high performance, reliability, power, low noise, low emissions, and low fuel consumption.

3. Superior Shell hydraulic oil protects key spare parts and extends the service life.

4. Safe and comfortable seating is equipped with a warning system, which alerts users when the seat belt is unfastened.

5. Exhaust fans in the gas forklift create a healthier working environment.

6. Our LPG forklift truck has an integrated overhead guard that protects the operators.

7. The eco-friendly design of the diesel forklift offers full protection to both the user and the environment.
8. Small overall dimension,low centre of gravity, small turning radius, and excellent manoeuvrability.
9. The frame and the steering axle of the material handling equipment are engineered with shock absorber to reduce the impact and maximize the comfort during operation.
10. Multiple engines for selection.



Parameters:

Model CPQD35
1 Feture Power Type   LPG
2 Load Capcity kg 3500
3 Load center mm 500
4 Lift height mm 3000
5 Free lift height mm 165
6 Forkk size L*W*H mm 1070×125×45
7 Mast tilt FR/RR . 6/12
8 Min turning Radius mm 2573
9 Min Right angle stacking aisle width mm 3573
10 Min right angle aisle width mm 2773
11 Min ground clearance mm 130
12 Height of overhead guard mm 2090
13 Overhang mm 474
14 Performance Max driving speed Full load km/h 18.5
15 Max Lifting speed Full load mm/s 420
16 Max drawbar pull Full load KN 28
17 Gradeabiity % 15
18 Dimension Overall length Without forks mm 2799
19 Over width mm 1230
20 Height mast lifted(with backrest) mm 4256
21 Height mast lowered mm 2065
22 Chassis Tyre Front   28×9-15-14PR
23 Rear   6.50-10-10PR
24 Wheelbase mm 1760
25 Tread FR/RR mm 1000/970
26 Self weight Without load Kg 4460
27 Drive Battery Voltage / Capacity V/Ah 12/80
28 Engine Model   Nissan K25
29 Rated Power kw/r.p.m 37.4/2300
30 Rated Torque Nm/r.p.m 176.5/1600
31 Bore * sTROKE mm 89×100
32 No.of Cylinder   4
33 Displacement L 2.488
34 Fuel tank capacity L 55
35 Transmission   1/1manual shift
36 Operating Pressure Mpa 18.5
37 Supplement Tire type (FR/RR)   Pneumatic
38 Numbers of wheels pcs 2/2
39 lowering speed (full load) mm/s 493
40 Lowering speed ( unload) mm/s 463
41 Axle load distribution (full load) (FR/RR) kg 7015/945
42 Axle load distribution (unload) (FR/RR) kg 1662/2798



Feartures:


Gas Powered LPG Forklift Trucks 3500KGS Load Capacity 3m - 6m Lift Height    Gas Powered LPG Forklift Trucks 3500KGS Load Capacity 3m - 6m Lift Height
Gas Powered LPG Forklift Trucks 3500KGS Load Capacity 3m - 6m Lift Height Gas Powered LPG Forklift Trucks 3500KGS Load Capacity 3m - 6m Lift Height
